SYGMAX Solar Inverter 3KW
SUYEEGO MPPT Solar Inverter 2200va 12v 3200va 24v Off Grid Inverter
Technical Features
1.Pure sine wave inverter
2.Programmable supply priority for PV,battery or Grid
3.High PV input voltage range(55~450VDC)
4.Buil-in Max 80A MPPT solar charger
5.Compatible with lithium-ion battery
6.Support BMS communication with Lithium battery
7.Smart battery charge design to optimize battery life
8.Overload,high temperature, inverter output short circuit protection
9.Cold start function
10.WIFI&GPRS available for 1OS and android
|
MODEL
|
SYGHB2212
|
SYGHB3224
|
||
|
Rated Power
|
2200VA/1800W
|
3200VA/3000W
|
||
|
INPUT
|
||||
|
Voltage
|
230VAC
|
|||
|
Selectable Voltage Range
|
170-280VAC(for personal computers)
90-280VAC(for home appliances) |
|||
|
Frequency Range
|
50Hz/60Hz (Auto sensing)
|
|||
|
OUTPUT
|
||||
|
AC Voltage Regulation (Batt.Mode)
|
230VAC±5%
|
|||
|
Surge power
|
4400VA
|
6400VA
|
||
|
Transfer Time
|
10ms (for personal computers)
20ms (for home appliances) |
|||
|
Wave form
|
Pure Sine Wave
|
|||
|
BATTERY & AC CHARGER
|
||||
|
Battery Voltage
|
12VDC
|
24VDC
|
||
|
Floating Charge Voltage
|
13.5VDC
|
27VDC
|
||
|
Overcharge Protection
|
15.5VDC
|
31VDC
|
||
|
Maximum charge current
|
60A
|
60A
|
||
|
SOLAR CHARGER
|
||||
|
MAX.PV Array Power
|
2000W
|
3000W
|
||
|
MPPT Range@ Operating Voltage
|
55-450VDC
|
|||
|
Maximum PV Array Open Circuit Voltage
|
450VDC
|
|||
|
Maximum Charging Current
|
80A
|
80A
|
||
|
Maximum Efficiency
|
98%
|
|||
|
PHYSICAL
|
||||
|
Dimension.D*W*H(mm)
|
405*286*98mm
|
405*286*98mm
|
||
|
Net Weight (kgs)
|
4.5kg
|
5.0kg
|
||
|
Communication Interface
|
RS232/RS485(Standard)
GPRS/WIFI(Optional) |
|||
|
OPERATING ENVIRONMENT
|
||||
|
Humidity
|
5% to 95% Relative Humidity(No-condensing)
|
|||
|
Operating Temperature
|
-10℃ to 55℃
|
|||
|
Storage Temperature
|
-15℃ to 60℃
|
|||
